INTEGRATION GUIDE FOR THE CANON RK F2

CANON RK F2 CONFIGURATION

Default settings when the instrument is shipped from Canon are as follows:

TRANS : OFF

[FMT] : 1

[BAU] : 19200.8N1

You need to set TRANS to ON and FMT to 3.. leave default BAU settings

CRYSTAL MACHINE UTILITY CONFIGURATION

Set up the Crystal PM Machine Utility using the following instructions: Crystal PM Machine Integration Utility Setup

Data Speed:	19200
Data Bits:	8
Parity:	Even
Stop Bits:	One
Flow Control:	None
Write Response:	6
Output:	Text (.txt) output

CRYSTAL CONFIGURATION

Add the Machine:

1. In Crystal, go to the Records tab

2. In Records, navigate to EHR Settings à Import Machines à Select an open Machine Slot

3. A window will open with a list a of machines, click on “Browse for available machines” at the bottom

4. Choose the machine labeled “Canon RK F2”

5. Browse to the .txt output location (C:/Program Files (x86)/CrystalPM/mach/mach1/mach1.txt)

6. Click open, then leave the Records tab in Crystal and then come back to it (Click on Tasks tab then click back onto records tab.)

Create the button in records:

1. In Records, navigate to EHR Settings à Edit Medical Record Templates

2. At the bottom of the Edit Fields Window click on “Add New Field”

3. Make the field type to be a button

4. Assign the fields in your template to the corresponding fields from the txt file below:

5. Add field to template and Save Changes

MACHINE BUTTON MAPPING

ID         Data           ___________________ 1 FileName 2 Date 3 VD 4 OD SPH 5 OD CYL 6 OD AXIS 7 OS SPH 8 OS CYL 9 OS AXIS 10 OD K1 mm 11 OD K1 diam 12 OD K1 Axis 13 OD K2 mm 14 OD K2 diam 15 OD K2 Axis 16 OD K Avg mm 17 OD K Avg Cyl 18 OS K1 mm 19 OS K1 diam 20 OS K1 Axis 21 OS K2 mm 22 OS K2 diam 23 OS K2 Axis 24 OS K Avg mm 25 OS K Avg Cyl 26 OD REST Cyl 27 OD REST Axis 28 OS REST Cyl 29 OS REST Axis
